LM-S2600 2.6 m³ Synchronized Rotary
The agile entry workhorse — cab and drum rotate together, drives both ways.
Key specifications
Full technical table below. Optional engines and configurations on request — tell us your site conditions and target price.
Get Full Spec Sheet
LM-S2600 highlights
The LM-S2600 is the most compact model in the synchronized rotary range. Its cab swings together with the mixing drum through 270°, giving a 180° fan-shaped discharge with no blind spots, and the whole upper structure can turn 180° so the truck simply drives out backwards on narrow roads — no turning space required.
With a 2.6 m³ batch output it is ideal for village road projects, small canals and daily concrete volumes of 80–100 m³, where a full-size transit mixer cannot reach and manual mixing is too slow.
- 270° synchronized cab + drum rotation, 180° fan discharge
- Bidirectional driving — no U-turn needed on narrow sites
- 4WD with 4 forward / 4 reverse dual high-low gearbox
- 2.6 m³ per batch, 3–5 batches per hour
- Timed automatic water system with 600 L tank
- Hydraulic self-priming pump for external water suction
Full technical specifications
| General | |
| Overall dimension (L×W×H) | 6650 × 2850 × 3200 mm |
| Wheelbase | 2760 mm |
| Tread | 2165 mm |
| Operating weight | 7,000 kg |
| Loader bucket capacity | 0.6 m³ |
| Driving form | Four-wheel drive (4WD) |
| Max. speed | 35 km/h |
| Max. gradeability | 35° |
| Min. turning radius | 3,900 mm |
| Min. ground clearance | 350 mm |
| Brake | Spring-applied air-release brake (duangqisha) |
| Powertrain | |
| Engine | Yuchai 4102 turbocharged diesel |
| Rated power | 77.3 kW (105 hp) |
| Transmission | ZL-280 hydraulic torque converter |
| Gears | 4 forward / 4 reverse, dual high-low speed |
| Fuel tank | 120 L |
| Hydraulic oil tank | 120 L |
| Engine oil | 16 L |
| Hydraulic system | |
| Reducer | Borrego 230B closed type |
| Main pump | Plunger pump R1-40/80 |
| Drum motor | Zhenjiang Dali 200 |
| Drum rotation speed | 17 rpm |
| Water & mixing | |
| Water tank | 600 L |
| Water supply | Timed relay, auto shut-off; hydraulic self-priming pump |
| Drum geometric capacity | 4 m³ |
| Concrete output per batch | 2.6 m³ |
| Output per hour | 10–10.4 m³/h |
| Discharge height | 2,000 mm |
| Running gear | |
| Tires | 16/70-20 steel-wire tires (Chaoyang / Linglong / Triangle) |
| Optional engines | Cummins 4BTA3.9-C125-II · Yuchai 6-cyl · Weichai Deutz WP4G130E22 |
Specifications may be optimized continuously; the commercial contract prevails. Custom colors, engines and attachments available.
Photo gallery
